PD80A portable real-time spectrum analyzer
Calibration type*
International standards：Compliant with ISO/IEC 17025, traceable to NISTHigh precision：± 0.1dB accuracy, dual review mechanism
Professional equipment：Calibration using high-end instruments from R&S and Keysight
Warranty period*
Our standard warranty period is 2 years. Extended warranty period up to five years (2-year warranty plus 3 years). Extended warranty is calculated at 6% of the annual product cost.
Product Introduction:
The PD80A radio acquisition, processing, and analysis module developed by Chengdu Kepuda Information Technology Co., Ltd. adopts a two-stage frequency conversion superheterodyne architecture, achieving wideband signal coverage from 20MHz to 6GHz (supporting 9kHz-30MHz in the shortwave frequency band). This module is equipped with an 80MHz real-time intermediate frequency bandwidth and can complete device power supply and data transmission through 1-2 USB 3.0 interfaces, meeting the requirements of portable deployment.
Technical specifications and functional features:
1. Frequency conversion architecture design
Adopting RF signal secondary down conversion processing technology, stable analysis of high-frequency signals is achieved through fixed intermediate frequency conversion. This architecture significantly reduces system power consumption while ensuring signal integrity.
2. Multi scenario adaptation capability
Power supply system: USB 3.0 interface provides 5V/1.7A power support, with a total power consumption of less than 9W
Hardware size: Core processing unit 195 × 80 × 30mm, total weight less than 1kg
Deployment form: Supports fixed monitoring stations, vehicle mounted mobile platforms, and portable rapid deployment.
3. Intelligent signal processing
Integrated feature recognition algorithm, capable of parsing conventional/unconventional frequency band ultra short wave/communication satellite/drone communication protocols, with non cooperative signal detection capability.
Indicator parameters:
What is inside the packaging box of PD80A?
PD80A portable spectrometer unboxing list:
-
- USB 3.0 high-speed data cable
- PD80A spectrum analyzer host (including shockproof packaging)
- Factory certificate of conformity (including unique equipment number and calibration information) Ready to use out of the box, professional measurement worry free.
